Specification(mm) Item			0.080	0.090	0.100	0.112	0.125	0.140	0.160	0.180	0.200	0.224	0.250	0.280	0.315	0.355	0.400	0.450	0.500	0.560	0.630	0.710	0.800	0.900	1.000	1.120	1.250	1.400	1.600	1.800	2.000	2.240	2.500
Winding around round bar(D)			After it is wired on a stipulated testing bar(D-enamel wire extemal diameter),the paint film shall not break down.
Drawing																														The paint film shall not crack after it is extended over 32%.
Emergent bursting			After emergent breakdown,the paint film shall not crack or lost its adhesion.
Stripping&wiring(=rpm)																										134	120	108	94	84	75	67	60
Thermal breakdown(=D)			3							4				5												7				Extending 10%
Softening breakdown			It shall not be broken diwn within 2mm under 240o
Paint scrapping(N)	Level1	Average											2.70	2.90	3.15	3.40	3.65	3.90	4.20	4.50	4.85	5.20	5.60	6.05	6.55	7.05	7.60	8.20	8.90	9.60	10.3	11.1	11.9
		Min											2.30	2.45	2.65	2.85	3.05	3.30	3.55	3.80	4.10	4.40	4.70	5.10	5.55	5.95	6.45	6.95	7.55	8.15	8.75	9.40	10.1
	Level2	Average											4.50	4.80	5.20	5.60	6.00	6.45	6.90	7.40	7.90	8.50	9.10	9.70	10.4	11.1	11.9	12.7	13.7	14.7	15.7	16.7	17.8
		Min											3.80	4.10	4.40	4.75	5.10	5.45	5.85	6.25	6.70	7.20	7.70	8.20	8.80	9.40	10.0	10.8	11.6	12.4	13.3	14.2	15.1
High temperature voltage(V)	Level 1					1000	1100	1200	1300	1300	1400	1400	1600	1700	1700	1700	1700	1700	1800	1900	2000	2000	2000	2000	2000	2000	2000	2000	2000	2000	2000	2000	2000
	Level 2					2000	2100	2300	2400	2500	2600	2800	2900	3000	3100	3200	3300	3300	3500	3500	3600	3600	3700	3800	3800	3800	3800	3800	3800	3800	3800	3800	3800
Thermal resistance(o)			130
