Specification(mm)
Item |
0.080 |
0.090 |
0.100 |
0.112 |
0.125 |
0.140 |
0.160 |
0.180 |
0.200 |
0.224 |
0.250 |
0.280 |
0.315 |
0.355 |
0.400 |
0.450 |
0.500 |
0.560 |
0.630 |
0.710 |
0.800 |
0.900 |
1.000 |
1.120 |
1.250 |
1.400 |
1.600 |
1.800 |
2.000 |
2.240 |
2.500 |
| Winding around round bar(D) |
After it is wired on a stipulated testing bar(d-conductor diameter),the paint film shall not break down. |
|
| Drawing |
|
The paint film shall not crack after it is extended over 32%. |
| Emergent bursting |
After emergent breakdown,the paint film shall not crack or lost its adhesion. |
|
| Stripping&wiring(=rpm) |
|
134 |
120 |
108 |
94 |
84 |
75 |
67 |
60 |
| Thermal breakdown(=D) |
1 |
Extending 32% |
| Softening breakdown |
It shall not be broken diwn within 2mm under 170o |
| Paint scrapping(N) |
Level 1 |
Average |
|
2.30 |
2.50 |
2.70 |
2.90 |
3.15 |
3.40 |
3.65 |
3.90 |
4.20 |
4.50 |
4.80 |
5.20 |
5.60 |
6.00 |
6.50 |
9.00 |
7.50 |
8.00 |
8.60 |
9.30 |
10.00 |
| Min |
|
1.95 |
2.10 |
2.30 |
2.50 |
2.70 |
2.90 |
3.10 |
3.30 |
3.55 |
3.80 |
4.10 |
4.40 |
4.75 |
5.15 |
5.55 |
5.95 |
6.35 |
6.80 |
7.30 |
7.90 |
8.50 |
| Level 2 |
Average |
|
4.10 |
4.40 |
4.75 |
5.10 |
5.45 |
5.80 |
6.20 |
6.65 |
7.10 |
7.60 |
8.10 |
8.70 |
9.30 |
10.00 |
10.70 |
11.40 |
12.20 |
13.10 |
14.00 |
14.90 |
15.90 |
| Min |
|
3.50 |
3.70 |
4.00 |
4.30 |
4.60 |
4.90 |
5.25 |
5.60 |
6.00 |
6.45 |
6.90 |
7.40 |
7.90 |
8.50 |
9.10 |
9.70 |
10.40 |
11.10 |
11.90 |
12.70 |
13.50 |
| Level 3 |
Average |
|
4.80 |
5.20 |
5.60 |
6.00 |
6.40 |
6.80 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Min |
|
4.10 |
4.40 |
4.80 |
5.10 |
5.50 |
5.80 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Solderability |
After soaked in the solder bath for 2s,itisshallbe smooth,free of pinholes and film residue. |
After soaked in the solder bath for over 3s,it shall have the same results. |
| Brine Test |
Perform according to the requirements of customers |
